ATV 200cc water cooled ATV 150cc ATV 200cc 4x4

Engine Type

Single cylinder, air-cooled, 4-stroke, fully automatic with reverse

Engine Displacement

150cc / 200cc

Bore & Stroke

57.40x57.80mm[200cc: 62.5x65.2mm]

Compression Ratio

10:1

Carburetor

Carburetor

Max. Power Output

6.0kW/(7500r/min) [200cc: 7.0kW/(7500r/min)]

Max. Torque

8.3N.m/(6000r/min)[200cc: 10.5N.m/(5500r/min)]

Ignition

CDI

Starter

Electric start & Kick start

Drive Train

Clutch

Manual

Gearbox

3-speed(forward, neutral and reverse gears)

Final Drive

Chain

Dimensions and Weight

Length x Width x Height

1,830x1,060x1,370mm

Wheelbase

1,210mm

Front Tread

930mm

Rear Tread

760mm

Seat Height

890mm

Foot Step to Seat

480mm

Fuel Capacity

7.8L, metal tank

Wheels, Suspension and Brakes

Wheels Front

8 inch / 10 inch alloy rim

Wheels Rear

8 inch / 10 inch alloy rim

Suspension Front

Independent double-wishbone

Suspension Rear

Swing arm with single shock

Brakes F/R

Dual drum brakes(Hand operated) / Hydraulic disc brake(foot operated)

Packing

Carton Size

1,500x830x810mm

G.W./N.W.

184/164kg

Container Load

22pcs/44pcs/66pcs
