Engine | |
Engine Type | Single cylinder, water-cooled, 4-stroke, manual |
Engine Displacement | 250cc |
Carburetor | Carburetor |
Max. Power Output | 12kW/(6500r/min) |
Max. Torque | 17.5N.m/(5500r/min) |
Ignition | CDI |
Starter | Electric start |
Drive Train | |
Clutch | Manual |
Gearbox | 5-speed(four forward gears and one reverse gear, plus neutral gear) |
Final Drive | Chain |
Dimensions and Weight | |
Length x Width x Height | 2,020x1,210x1,260mm |
Wheelbase | 1,400mm |
Front Tread | 970mm |
Rear Tread | 970mm |
Seat Height | 750mm |
Foot Step to Seat | 480mm |
Fuel Capacity | 7.8L, metal tank |
Dry Weight | 164kg |
Max. Speed | 70km/h |
Wheels, Suspension and Brakes | |
Wheels Front | 14 inch iron rim / 14 inch iron rim |
Tyres F/R | 270/30-14 / 270/30-14 |
Suspension Front | Independent double-wishbone / Swing arm with single shock |
Brakes Rear | Dual hydraulic disc brakes / Hydraulic disc brake |
Packing | |
Carton Size | 197x122x97cm |
G.W./N.W. |
|
